Overall Operating Weight

8000KG

Transport Dimension

 L*W*H

8000×2200×2900mm

軸距 Wheel base

2250mm

最小離地間隙

Min. Ground Clearance

300mm

裝載斗容 Bucket Capacity

1.5m3

掘起力Breakout Force

38KN

裝載舉升能力

Loading Lifting Capacity

2800KG

鏟斗卸載高度

Bucket Dumping Height

2800mm

鏟斗卸載距離

Bucket Dumping Distance

1062mm

鏟挖深度 Digging Depth

52mm

反鏟斗容

Backhoe Capacity（Width）

0.35m3(620mm)

最大挖掘深度

Max. Digging Depth

4100mm

挖斗回轉角

Swing Angle of backhoe

190o

最大牽引力

Max. Pulling Force

39KN

發動機Engine

型號Model

YUCHAI

型式Type

單列、直噴、四沖程、水冷

In Line，Direct injection，F(xiàn)our-Stroke，Water Cooling

額定功率Rated Power

85KW

發動機選配：Optional engine

DONGFENG CUMMINS 75KW/  CUMMINS 92KW/ CUMMINS Euro3 75KW

轉向系統Steering System

轉向角Steering Angle

±36 o

最小轉彎半徑

Min. turning radius

6581mm

系統壓力

Pressure of the system

12Mpa

驅動橋Axle

品牌Brand

肥城云宇橋FEICHENG YUNYU

主傳動類型

Main Transmission Type

雙減速

Double Reduction

輪邊減速型式Final Reducer

一級輪邊減速Single Stage Final Reducer

額定載重

Rated Loader of Axle

4/18.5t

傳動系統Transmission System

變矩器Torque Converter

型號Model

YJ280

型式Type

單級、單相三元件Single-stage Three Elements

冷卻方式Cooling Method

油冷壓力循環Oil-cooling Pressure Circulation

變速箱Gearbox

型式Type

定軸式動力換檔Fixed Shaft Power Transmission

檔位數Gears

前進2檔，后退2檔Two Gears Ahead, Two Gears Astern

最高車速M(fèi)ax.Speed

30Km/h

輪胎Tyre

規格Model

（F）14-17.5前輪

（R）19.5L-24后輪

前輪氣壓

Pressure of Front wheel

0.22 Mpa

后輪氣壓

Pressure of Back Wheel

0.22 Mpa

制動系統Brake System

行車制動Service Brake

氣頂油鉗盤制動Air Over Oil Caliper Brake

外置式External Type

自調節Self-regulation

自平衡Self-balance

駐車/緊急制動

Emergency Brake

操縱力實施制動Operation Power Implementing brake

手操縱力解除制動Manual Operation Power Terminating Brake

液壓系統Hydraulic System

液壓系統壓力

Pressure of Hydraulic System

22Mpa

挖斗挖掘力

Digging Power of Excavator Grab

46.5KN

鏟斗掘起力

Digging Power of Dipper

31KN

鏟斗提升時間

Bucket Lifting Time

5.4S

鏟斗下降時間

Bucket Lowering Time

3.1S

鏟斗卸料時間

Bucket Discharge Time

2.0S
