Total operating weight總重量

7200Kg

Length*width*height(mm)長寬高

7600x2260x2900

Wheel base軸距

2250mm

Axle track輪距

1700mm

Minimum ground clearance最小離地間隙

300m

Loading bucket capacity鏟斗容量

1.3m3

Digging up capacity挖掘力

38KN

Loading lift capacity載重

2500Kg

Bucket discharge height前鏟卸載高度

2742mm

Bucket discharge distance前鏟卸載距離

1062mm

Backhoe bucket capacity挖斗容量

0.3m3

Backhoe discharge height后挖卸載高度

3878mm

Maximum digging depth最大挖掘深度

4000mm

Optional Digging Depth可選挖深

5000mm-5500mm（挖臂伸縮Digging boom telescopic）

Bucket slewing angle鏟斗回轉角度

180°

Bucket stick revolving radian挖斗旋轉弧度

180°

Maximum puling force最大推力

39KN

Engine發動機

Model型號

渦輪增壓YUNNEI YN38GBZ turbo engine

Type型式

直列，直噴，四沖程，水冷

Inline, direct injection, four-stroke, liquid cooled

Rated power額定功率

76KW

Optional engine可選發動機

歐五4G33TC-75L常柴55.2KW

EPA4/歐五科勒KDI2504TCR發動機55KW

EPA4康明斯55KW發動機QSF2.8     EPA4康明斯QSF3.8

75KW康明斯4BT3.9-C100    玉柴YCF36100-S500歐五74KW

Steering system轉向系統

Type型式

Articulated hydraulic steering鉸接式液壓轉向

Steering angle轉向角度

36°

Minimum turning radius最小轉彎半徑

3660mm

System pressure系統壓力

16Mpa

Transmission system傳動系統

Torque converter變速箱

280

Type of gearbox變速箱型式

Fixed shaft power shift transmission定軸式

Gear變速箱

2gears ahead,2gears reverse前二后二

Maximum speed最大速度

30KM/H

Drive axle驅動橋

Drive type驅動型式

Four-wheel drive 四輪驅動

Wheel reduction type輪邊減速型式

Single stage planetary type單級行星式

Tire輪胎

Tire size輪胎型號

16/17-20

Front wheel pressure前輪氣壓

0.22Mpa

Rear wheel pressure后輪氣壓

0.22Mpa

制動系統Brake System

Service braking腳剎

Air over hydraulic caliper disc brake parking氣頂油碟剎

Emergency brake手剎

Flexible shaft operated disc brake軟軸控制碟剎

Hydraulic system液壓系統

Pressure of Hydraulic System液壓系統壓力

22Mpa

Packing Quantity（1*40HC）裝箱量

2Units(拆輪胎/挖臂/鏟斗)

Standard標配：前鏟帶鏟斗，后挖帶挖斗，豪華內飾駕駛室?guī)拼板N/滅火器/LED燈/前后雙攝像頭大倒車影像/前后雨刮器/風扇/暖風，豪華可調式旋轉座椅，可調式儀表盤，液晶顯示屏，前鏟后挖液壓先導操作，云內76KW發動機，16/70-20輪胎，280整體變速箱，高頻加重大輪邊橋，A形支腿帶鎖止。
