Model型號

Unit

HT10-70

Performance Parameters參數

Dead-Weight自身重量

kg

4200

Canopy/Cabin遮陽棚/駕駛室

Cabin

Bucket斗

Capacity斗容量

m3

0.06

Width斗寬

mm

400

Max. digging force最大挖掘力

kN

12

Arm digging force臂挖掘力

kN

4.5

basket鏟斗

Bucket capacity      鏟斗斗容

m3

0.6

Bucket width          鏟斗斗寬

mm

1800

Engine發動機

Brand/Model品牌/型號

云內          YN27GB

Rated power/speed額定功率/轉速

58/2400

Displacement排量

lt

2.7

Main Pump主泵

Brand品牌

天津泰特 TAITE

Pump type泵型號

T50/25/25

Flow rate流速

lt/min

100/50/50

Traveling motor行走馬達

cc

Running speed (high/low)行走速度（高速/低速）

km/h

26

Pressure of the system系統壓力

Mpa

16

Max. traction最大牽引力

kN

25

Ground pressure對地壓力

kPa

180

Gradeability爬坡能力

°

30

Fuel tank capacity燃油箱容量

lt

45

Hydraulic oil tank capacity液壓油箱容量

lt

45

傳動系統Transmission System

Gearbox變速箱

Gears檔位數

Driving form驅動形式

Scope of Work工作范圍

挖斗工作范圍

Max. digging height最大挖掘高度

mm

3500

Max. dumping height最大傾倒高度

mm

2000

Max. digging depth最大挖掘深度

mm

2000

Max. vertical digging depth最大垂直挖掘深度

mm

2000

Max. digging radius最大挖掘半徑

mm

3400

鏟斗工作范圍

Maximum dumping height 鏟斗卸載高度

mm

3300

Loading and lifting capacity裝載舉升能力

kg

1200

Maximum Rising Power最大崛起力

KN

25

Outline Dimensions外觀尺寸

Overall Dimension (LxWxH)                        整體尺寸（長*寬*高）

mm

5400X1870X2750

Wheel tread輪距

mm

1510

Wheel base軸距

mm

2200

Chassis ground clearance底盤離地間隙

mm

280

Tyre輪胎

Model規格

mm

23.5/70-16

Pressure of Front wheel前輪氣壓

Mpa

2.5

Pressure of Back wheel后輪氣壓

Mpa

2.5
